dB Technologies FMX15 15'' Active Floor Monitor

Monitoring the right way

Completely adaptable monitoring. The dB Technologies FMX15 is built to meet your needs. From rotatable horns, to a built-in ergonomic handle and pole mount. The FMX15 is versatile in every sense of the word. The FMX15's eight built-in presets allow you to ensure that you're always sounding your best. From Live Monitor, Coupled Monitors, Male or Female Singer, and Antifeedback to name a few, you can be prepared for any situation.

Advanced processing

Intelligent and effective. The FMX15's integrated DSP takes care of your sound to ensure that it's delivered with outstanding clarity. Simply select one of the eight presets to suit your needs, and the monitor will do the rest. The DSP also takes advantage of linear phase FIR filters. These ensure that your sound is reproduced with zero phase distortion or delay distortion. So you can enjoy crystal-clear, uniform sound and exceptional system optimisation every single night.

Built for the road

It takes more than a solid cabinet to achieve the reliability you want. And that's exactly why FMX monitors have been built with meticulous attention to detail. From the robust plywood enclosures, to the unique front-rear grille design, and the use of premium components. Every aspect of these rugged monitors has been crafted to give you the durability you deserve.

And when it comes to living with your monitor through day to day use, you'll feel free. An ergonomic handle has been built into the bottom side of the cabinet, enabling you to transport, maneuver, and position your monitor with ease. Plus, you can mount your FMX monitor on a speaker stand or pole thanks to an integrated 36mm pole receptacle on the side panel. And no matter what position you use your monitor in, you'll still have full access to the controls on the opposite side panel.

Features

• 2-way active stage monitor with a coaxial design
• 600W RMS Class-D amplifier drives a 15'' LF woofer and 1'' HF transducer
• Custom rotatable horn design for optimising directivity
• Advanced DSP with linear phase FIR filters for even, intelligible sound
• Eight on-board presets adapt the EQ for different needs
• Intuitive operation with exceptional sonic results
• Innovative front-rear grille design protects your components
• Robust plywood cabinet for maximum durability
• 36mm pole receptacle provides an easy mounting solution
• Ergonomic handle allows for hassle-free maneuverability

Specifications

• Speaker Type: 2-way active coaxial stage monitor
• Frequency Response:
  • -10dB: 46Hz - 19kHz
  • -6dB: 50Hz - 15.5kHz
• Maximum SPL: 128dB
• HF Transducer: 1'' exit, 1.3'' voice coil
• Horn: Rotatable
• Directivity: 60° x 90° (H x V)
• LF Transducer: 15'' diameter, 2'' voice coil
• Crossover: 1740Hz (24dB/oct)
• Amp Class: Class-D
• Power: 600W (RMS) / 1200W (peak)
• PSU Technology: SMPS
• Controller: DSP 28/56-bit
• AD/DA Converter: 24-bit/48kHz
• System Presets: 8 presets
• Limiter: Peak, RMS, Thermal
• Advanced DSP Function: FIR filters
• Controls: DSP programs rotary encoder, Line/Mic switch, Input Sensitivity level
• Signal Inputs: 1 x balanced XLR connector
• Signal Out/Link: 1 x balanced XLR connector
• Mains Connection: VDE
• Housing:
  • Material: Plywood
  • Design: Multifunctional
  • Grille: Full metal
  • Handles: 1 x integrated on bottom side
  • Pole Mount Receptacle: 36mm
• Operating Voltage: 220-240V, 50-60Hz
• Power Draw: 1.2A (at 1/3 of full power in maximum use conditions)
• Dimensions: 500mm x 340mm x 500mm / 19.68'' x 13.38'' x 19.68'' (W x H x D)
• Weight: 16.9kg / 37.2lbs
• SKU: FMX15
